DMTA-20015-01EN [U8778402], Rev. J, January 2014
Overview of the Equipment
79
7.1.4 Up and Down Keys
The Up and Down keys can be used to navigate the interface without having to use
the scroll knob and Accept key in the main control area.
Up key ( )
Used to move upward in a vertical list, or to the right in a horizontal list.
Down key ( )
Used to move downward in a vertical list, or to the left in a horizontal list.
When these two keys are pressed simultaneously, they perform the same function as
the Accept key in the main control area.
7.1.5 Menu Key
The blue Menu key is located on the upper left side of the OmniScan MX front panel.
Menu key ( )
Used to automatically display all available menus from almost any location
within the software.
7.1.6 Submenu Keys
The submenu keys are labeled F2, F3, F4, F5, and F6 ( to ), and are located on
the left side of the OmniScan MX front panel.
Each of these keys is used to select the submenu that appears next to it.
7.1.7 Help Key
The yellow Help key is shaped in the form of an inverted triangle, and located on the
lower-left side of the OmniScan MX front panel.
Help key ( )
Pressing this key displays the online help for the function currently selected.
