Figure 7-1 Front panel of the OmniScan MX
7.1.1 Main Control Area
The main control area is shown in Figure 7-1 on page 76. You can control the
OmniScan MX completely from this area if you wish. The main control area contains
three elements, which are described in Table 16 on page 77.
Main
control
area
Function
keys
Parameter
keys
Power key
Help key
Menu
key
Up/down
keys
Power
indicator light
Submenu keys
Keypad
indicator
light
Alarm indicator
lights
Acquisition
indicator light
Display
screen
