Appendix D: OMNI-M-UT-2C, OMNI-M-UT-4C, and
OMNI-M-UT-8C Module Specifications
This appendix presents the technical specifications for OmniScan UT acquisition
module models OMNI-M-UT-2C, OMNI-M-UT-8C (see Figure D-1 on page 139), and
OMNI-M-UT-4C.
Figure D-1 Modules OMNI-M-UT-2C (left) and OMNI-M-UT-8C (right)
