DMTA-20015-01EN [U8778402], Rev. J, January 2014
Labels and Symbols
6
The membrane vent (see Figure i-4 on page 6) is used to counterbalance the internal
and external pressure, and to maintain the instrument’s watertight integrity. Do not
puncture the membrane vent. Puncturing of the membrane vent will result in the
instrument’s failure to comply with the IP rating.
Figure i-4 The OmniScan MX2 membrane vent
