E.3 Data Specifications
This section details the data specifications of processing and TCG (see Table 43 on
page 146).
Table 43 Data specifications
Processing
Real-time averaging 2, 4, 8, and 16
Rectification RF, full wave, half wave+, half wave–
Filtering Low-pass (adjusted to probe frequency),
digital filtering (bandwidth, frequency
range).
Video filtering Smoothing (adjusted to the probe frequency
range).
Programmable TCG
Number of points 16: One TCG (time-corrected gain) curve
per channel for focal laws.
Storage
C-scan recording I, A, B, up to 10 kHz
Maximum file size Limited to available internal flash memory:
OmniScan MX: 180 MB (or 300 MB
optional).
OmniScan MX2: 300 MB
