Olympus OmniScan MX2 - Acquisition Specifications; D.2 Acquisition Specifications; Data Specifications; Table 39 Acquisition Specifications

DMTA-20015-01EN [U8778402], Rev. J, January 2014
OMNI-M-UT-2C, OMNI-M-UT-4C, and OMNI-M-UT-8C Module Specifications 141
D.2 Acquisition Specifications
This section lists the acquisition specifications for frequency, data display, and
synchronization (see Table 39 on page 141).
D.3 Data Specifications
This section outlines the data specifications for processing, TCG, and storage (see
Table 40 on page 141).
Table 39 Acquisition specifications
Frequency
Digitizing frequency 100 MHz (10 bits)
A-scan (acquisition
mode)
Up to 6000 A-scans per second (512-point,
8-bit A-scan)
Maximum pulsing rate Up to 10 kHz (C-scan)
Depth in material 59.8 meters in steel (L-wave), 10 ms with
compression
0.49 meter in steel (L-wave), 81.9 µs without
compression
Display
Refresh rate A-scan: 60 Hz
Envelope (echo-dynamic
mode)
Yes
Synchronization
On internal clock 1 Hz to 10 kHz
External pace Yes
On encoder On 2 axes: from 1 to 65536 steps
Table 40 Data specifications
Processing
Number of data points Up to 8000
Real-time averaging 2, 4, 8, 16
Rectification RF, full wave, half wave +, half wave –
