DMTA-20015-01EN [U8778402], Rev. J, January 2014
OMNI-M-ECT4 Module Specifications
171
Appendix L: OMNI-M-ECT4 Module Specifications
The OMNI-M-ECT4 module is compatible with the OmniScan MX only.
This appendix presents eddy current (ECT) acquisition module model
OMNI-M-ECT4, which can be used with the OmniScan MX unit.
L.1 ECT Acquisition Module Description
The OMNI-M-ECT4 acquisition module (See Figure L-1 on page 172) is designed for
durability and simplicity. Any conventional eddy current probe with up to four
channels can be connected to the module.
L.2 ECT Acquisition Module Receptacles
The ECT acquisition module is equipped with two receptacles on the left side.
1CH
BNC receptacle for one single-coil eddy current probe using conventional eddy
current technique.
4CH
A 19-pin receptacle used for eddy current probes with up to four single coils.
