Olympus OmniScan MX2 - Page 154

DMTA-20015-01EN [U8778402], Rev. J, January 2014
Appendix D 142
Video filtering Smoothing (adjusted to probe frequency
range)
Filtering Centered at:
1MHz
2MHz
5MHz
10 MHz
15 MHz
20 MHz
Band-pass filter:
0.25 MHz to 2.25 MHz ±10 %
2 MHz to 25 MHz ±10 %
Programmable TCG
Number of points 16: One TCG (time-corrected gain) curve
per channel
Maximum gain 40 dB
Maximum slope 20 dB/µs
Step 0.1 dB
Synchronization Pulser or gate I
Storage
A-scan recording (TOFD) 6000 A-scans per second (512-point, 8-bit
A-scan)
C-scan recording I, A, B, up to 10 kHz
Maximum file size Limited to available internal flash memory:
OmniScan MX: 180 MB (or 300 MB
optional)
OmniScan MX2: 300 MB
Table 40 Data specifications (continued)
