I/O ports
USB ports 2 USB ports compliant with USB 2.0
specifications: OTG
a
(On-the-Go) USB,
USB High Speed (HS)
1 USB port compliant with USB 1.1
specifications: USB full-speed (FS)
USB HS and OTG USB (host mode) can
operate at high speed, full speed, and
low speed
USB FS can operate at full speed and
low speed
Theoretical speed:
HS: 480 Mbps (megabits per second)
FS: 12 Mbps
LS: 1.5 Mbps
Video output Video out (SVGA)
Ethernet 10/100 Mbps
I/O lines
Encoder 2-axis encoder line (quadrature or
clock/direction)
Digital input 4 digital inputs TTL, 5 V
Digital output 4 digital outputs TTL, 5 V, 15 mA
maximum per output
Remote
communication
Remote communication RS-232: 2 serial
ports using 3-wire RS-232
Acquisition on/off
switch
Remote acquisition enable TTL, 5 V
Power output line 5V nominal, 500mA maximum,
shared between both Serial Out
connector and Scanner connector
power output (short-circuit protected)
Table 10 OmniScan MX2 general specifications (continued)
