CT Analyzer User Manual
166 OMICRON
Note: The reactance measurement uses the serial equivalent circuit diagram for results calculation.
Use the following wiring for reactance measurement (example):
Figure 10-22: Wiring example for reactance measurement
f Frequency measured at input SEC.
Ls or Cs Serial inductance or capacitance of the test object, calculated from the measured
values.
CT Analyzer automatically detects whether the test object is an inductance or a
capacitance based on the phase angle.
Table 10-16: Values displayed for Reactance measurement type (continued)
Value Description
