OMICRON 79
Operating and configuring CT Analyzer
6.11 CT Analyzer help system
CT Analyzer provides a context-sensitive help system. Pressing the key displays a help page, the
content of which depends on where the focus was set before the key was pressed.
For example:
► If the focus is set to the CT-Object card’s tab, pressing the key displays a help page showing
the wiring for a CT test.
► If the focus is set to the Burden card’s tab, pressing the key displays a help page showing the
wiring for a burden test.
â–º If a parameter field in the CT-Object card or the Assessment card is selected with the cursor,
pressing the key displays a help page with explanatory texts for this specific parameter.
Figure 6-17: Help system showing the wiring diagram for a CT test (left) and explanatory text for a
parameter (right)
When the help system is displayed, you can use the Next Page and Prev. Page soft keys to scroll
through the available help pages. Pressing the About soft key opens a page with information about the
CT Analyzer hardware, the installed firmware version, the serial number, etc.
6.12 Operating CT Analyzer from a computer
It is also possible to operate CT Analyzer remote controlled from a computer using the
CT Analyzer Suite software.
For more detailed information, please refer to chapter 11 on page 167 and the CT Analyzer Suite help.
