Omicron CT SB2 User Manual

OMICRON 59
Technical data
Figure 10-2: CTA interface on CT SB2
Figure 10-3: Connection cable CT SB2 to CT Analyzer
10.3 Environmental conditions
Table 10-2: Environmental conditions
Characteristic Rating
Operating temperature –10 … +50 °C (14 … 122 °F)
Storage and transportation –20 … +70 °C (–4 … 158 °F)
Max. altitude for operation 2000m
15
69
CTA interface
9-pole SUB-D connector, male
Outside view onto the pins on CT SB2!
Connections required:
12345678shield
12345678shield
9-pole (DB9) null modem or
crossover cable, 2 x female

Omicron CT SB2 Specifications
