CT SB2 User Manual
60 OMICRON
10.4 Mechanical data
10.5 Standards
Table 10-3: Mechanical data
Characteristic Rating
Weight 2.6kg (5.7lbs) without accessories
Dimensions W x H x D 285 x 68 x 225mm (11.2 x 2.7 x 8.9")
Table 10-4: Standards
EMC, safety
EMC
IEC/EN 61326-1 (industrial electromagnetic environment)
FCC subpart B of part 15, class A
Safety IEC/EN/UL 61010-1
Other
Shock IEC/EN 60068-2-27 (15 g/11 ms, half-sinusoid, 3 shocks in each axis)
Vibration
IEC/EN 60068-2-6 (frequency range 10 Hz…150 Hz, acceleration 2 g
continuous (20 m/s
2
/65 ft/s
2
), 20 cycles per axis)
Humidity
IEC/EN 60068-2-78 (5%…95% relative humidity, no condensation),
tested at 40 ºC/104 ºF for 48 hours
Protection class IP20 according to EN 60529
