6.3 New CT-Test
By selecting "New CT-Test" in the main menu and then pressing the OK soft key,
a new CT test is displayed in the CT-Object card.
Figure 6-5: CT-Object card with default test settings after initializing a new CT test
For more detailed information about the parameters and fields in the CT-Object card of the CT Test
mode, please refer to section 7.2 on page 81.
6.4 New MR-Test
Using the "New MR-Test" option in the main menu you can initialize a new multi-
ratio CT test using the optional CT SB2 switch box.
This option is only available if you have purchased a corresponding license. For
more detailed information about multi-ratio CT testing using the CT SB2 switch
box, please refer to the CT SB2 User Manual.
6.5 New Advanced CT-Test
By selecting "New Advanced CT-Test" in the main menu and then pressing the OK
soft key, a new Advanced CT test with the default parameter settings is loaded and
displayed in the CT-Object card. Some of the default values can be defined in the
default test settings (see section 6.8 on page 66).
Figure 6-6: CT-Object card with default test settings after initializing a new Advanced CT test
This option is only available if you have purchased a corresponding license. For more detailed
information about the parameters and fields in the CT-Object card of the Advanced CT Test mode,
please refer to section 8.2 on page 90.
Press the Main soft key in
any test card
Main Menu:
- New CT-Test
OK soft key
-> CT-Object card
How to get there:
Press the Main soft key in
any test card
Main Menu:
- New MR-Test
OK soft key
-> CT-Object card
How to get there:
Press the Main soft key in
any test card
Main Menu:
- New Advanced
CT-Test
OK soft key
-> CT-Object card
How to get there:
