OMICRON 53
CT testing in Advanced CT Test mode ("New Advanced CT Test")
5.1 Short guide (Advanced CT Test mode)
This short guide does not consider residual magnetism measurement (see section 8.4 on page 109).
Figure 5-1: Short guide for testing in Advanced CT Test mode (1)
Set up CT Analyzer
-> 3.2 on page 25
Switch CT Analyzer on.
Select New Advanced CT Test
from main menu
-> 5.2.2, step 1. on page 55
Select test cards
-> 5.2.2, step 2. on page 55
Enter CT name plate data
-> 5.2.2, step 3. on page 55
Burden test card
enabled?
Select test current for
burden test
-> 5.2.2, step 4. on page 57
Start test
-> 5.2.3, step 1. on page 57
see next page
Yes
No
