OMICRON 81
Test cards for CT Test mode
7.2 CT-Object card
The CT-Object card of the CT Test mode holds all necessary settings for the test.
Figure 7-1: CT-Object card with default settings after initializing a new test
7.2.1 Available soft keys
7.2.2 Information fields to be filled by the user
Figure 7-2: Editing the location settings in the CT-Object card
The "Location" and "Object" text fields are only used for reporting and documentation purposes. They
can be filled by the user after the test is finished. These fields provide information about the location of
the CT and the CT itself. The content of these fields is defined in the Location settings page and the
Object settings page, respectively.
Table 7-2: Soft keys available in the CT-Object card
Soft key Description
Clears the results of the previous test and enables to start a new test. Text entries for
"Location" and "Object" remain unchanged.
Saves the test results and test settings to the currently loaded CT Analyzer report file. If
the test results have not been saved yet, the Save As dialog is opened. Saving a file is
described on page 78.
Saves the test results and test settings to a new .xml file. Saving a file is described on
page 78.
Allows to load a test previously performed in the CT Test mode and stored on the
Compact Flash card in order to check its results or to use its settings for a new test.
When loading a test stored in the Advanced CT Test mode, CT Analyzer will
automatically switch to the Advanced CT Test mode.
Press to open the main menu
