CT Analyzer User Manual
62 OMICRON
6 Operating and configuring CT Analyzer
6.1 Working in the user interface
6.1.1 Displaying a specific card
To display a specific card, select the card by pressing the card selection keys .
The card’s tab showing the name of the selected card is then highlighted (see Figure 6-1).
Figure 6-1: CT-Object card selected
6.1.2 Using the soft keys
Using the soft keys you can operate CT Analyzer and change the user interface level of the software.
The functionality of the soft keys is context-dependent, i.e., the software offers different functions or
selectable sets of parameters depending on the focus (i.e., depending on which card or field is
highlighted or selected in the user interface).
If the lowermost soft key description field contains 3 points (see Save As in Figure 6-1), additional soft
key functions are available. Then you can switch the set of displayed soft keys using the key
located below the soft keys (see Figure 6-2).
Figure 6-2: Switching the set of soft keys in the CT-Object card
...
1st set of soft keys
Press
2nd set of soft keys
