CT SB2 User Manual
14 OMICRON
3.3 CT SB2 accessories (scope of delivery)
The following accessories are delivered with the CT SB2 switch box:
Table 3-1: CT SB2 accessories
Accessory Description
1 x 6-pole cable Cable for connecting CT SB2 to CT Analyzer
1 x 12-pole cable,
7m (22ft)
Test cable for connecting the secondary side
of the CT to CT SB2
1 x 4-pole cable,
7m (22ft)
Test cable for connecting the burden to
CT SB2
1 x 9-pole SUB-D cable,
0.3m (1ft)
Data connection cable from the CTA
interface on CT SB2 to the remote control
interface on CT Analyzer
12 x clamp Clamps in 6 different colors according to the
12-pole test cable for connecting the test
cable plugs to the tap connections on the
secondary side of the CT
1 x Power cord adapter Using this adapter, only one power supply
cord is required to supply CT Analyzer and
CT SB2
1 x Cable bag Bag for cables and accessories
