OMICRON 63
Operating and configuring CT Analyzer
6.1.3 Editing a card
To open the edit mode for a displayed card, press the cursor key. The card’s tab is then no longer
highlighted (see Figure 6-3). Use the cursor keys to move the cursor and to select the desired edit field.
Some edit fields have soft keys assigned. The soft keys available for an edit field are displayed if the field
is selected.
Figure 6-3: Edit field selected in the CT-Object card
Proceed as follows to edit a card:
1. Select the edit field using the cursor keys.
2. Enter or edit the value or text:
► Select an entry offered by the soft keys (if available)
► or enter the value or text using the keyboard and then press the key to confirm your input
or use the key to leave an edit field without applying and saving the entry.
3. Leave the edit mode either by moving the cursor to the card’s tab using the cursor key or by
pressing the key. The focus is then set to the card’s tab again (tab highlighted).
6.2 The main menu
The main menu can be opened from any test card by pressing the Main soft key.
The items in the list can be selected using the cursor keys. When an item
is selected (highlighted), the soft keys are labeled with the functions available for
this specific item.
Figure 6-4: Main Menu page
Display field
(selection not possible)
Edit field
Edit field selected
Press the Main soft key in
any test card
-> Main Menu
How to get there:
