Default settings on CT Analyzer for multi-ratio CT testing using CT SB2
Number of Taps Only available if Mode at Startup = Multi-Ratio.
The number of taps is the overall number of tap connections available on the
multi-ratio CT.
Select the default number of taps using the soft keys No. of Taps 2 to
No. of Taps 6.
The number of taps defined here is applied as default for new multi-ratio tests
initialized in the MR Test mode or the Advanced MR Test mode.
Common Tap Only available if Mode at Startup = Multi-Ratio.
The common tap is the tap that is used as reference for all tap combinations
(e.g. X1-X2, X1-X3, X1-X4, etc. if common tap is X1).
Select the default common tap using the soft keys X1 and X#, where # is the
highest tap number available depending on the selected number of taps.
The common tap defined here is applied as default for new multi-ratio tests
initialized in the MR Test mode or the Advanced MR Test mode.
Table 7-1: Options in the Set Startup Mode page
