6 Troubleshooting
6-14
CP1E CPU Unit Hardware User’s Manual(W479)
z Reference
z Reference
z Reference
z Reference
Error flag
Backup Memory Error Flag, A315.15
Other Non-fatal Error Flag, A402.00
Error code (A400) 00F1
Error information −
PLC Setup Errors
Cause Remedy
A set value error occurred in the PLC Setup. The
address of the error is stored in A406 in 16-bit
binary.
Correct the PLC Setup with correct values.
Error flag PLC Setup Error Flag, A402.10
Error code (A400) 009B
Error information PLC Setup Error Location, A406
Option Board Errors
Cause Remedy
The Option Board is removed while the power is
being supplied. (A315.13 will turn ON.)
Turn OFF the power supply and then install the Option
Board again.
Error flag
Option Board Error Flag, A315.13
Other Non-fatal Error Flag, A402.00
Error code (A400) 00D1
Error information −
Battery Errors
Cause Remedy
If the PLC Setup is set to detect battery errors, this
error will occur when there is an error in the battery
in the CPU Unit (i.e., the voltage is low or a battery
is not mounted).
Check the battery connections.
Change the PLC Setup setting if battery-free operation is
being used.
Error flag Battery Error Flag, A402.04
Error code (A400) 00F7
Error information −

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
