Omron CP1E Series User Manual

A-21
Appendices
CP1E CPU Unit Hardware User’s Manual(W479)
A-3 Wiring Diagrams
App
A-3-2 Expansion I/O Units
Inputs not provided. Lower Terminal Block
20-point I/O Units
Input Wiring Diagram Output Wiring Diagram
z All Models z Relay Outputs
CP1W-20EDR1
z Transistor Outputs (Sinking)
CP1W-20EDT
Input Wiring Diagram Output Wiring Diagram
L L L
L
L L
L
L
L L L LLLLL
00 01 02 03 04 06 00 01 03 04 06
NC COM COM COM 05 07 COM 02 COM 05 07COM
NC
CIO n+3
CIO n+3
CIO n+2
CIO n+2
COM 01 03 05 07 09 11
NC 00 02 04 06 08 10
-
+
-
+
CIO m
CIO m
24V DC
00 01 02 04 05 07
COM COM COM 03 COM 06
L
L
L LLLLL
CIO n
L
L L L L L
L
L
COM COM COM COM03 06
00
01 02 04 05 07
CIO n

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
