Appendices
A-40
CP1E CPU Unit Hardware Userâs Manual(W479)
z Application Example
Note The following cables can be used for this connection.
It is recommended that one of these cables be used to connect the RS-232C port on the Option Board
to the NT-AL001 RS-232C/RS-422 Conversion Unit.
z Wiring for the Recommended Cables (XW2Z-070T-1 or XW2Z-200T-1)
Note The hood (FG) is internally connected to the ground terminal (GR) on the CPU Unit.
Therefore, FG is grounded by grounding the ground terminal (GR) on the power supply termi-
nal block.
Precautions for Correct UsePrecautions for Correct Use
⢠The XW2Z-î
î
0T-1 Connecting Cables for the NT-AL001 Link Adapter uses special wiring for
the DS and RS signals.
Do not use these signals with other devices.
Connecting this cable to other devices can damage them.
⢠Always turn ON the terminating resistance if the node is at the end of the RS-422A/485 trans-
mission path.
Length Model numbers
70cm XW2Z-070T-1
2m XW2Z-200T-1
NT-AL001
3
2
4
5
6
7
8
9
RD
SD
RS
CS
+5V
DR
ER
SG
FG
4
3
6
5
1
SDA
SDB
RDA
RDB
GRD
RDA
RDB
SDA
SDB
RS-422
RDA
RDB
SDA
SDB
SD
RD
RS
CS
+5V
DR
ER
SG
FG
2
3
4
5
6
7
8
9
FG
RS-232C
CP1E N-type CPU Unit
Built-in RS-232C Port or RS-232C
Option Board
RS-232C/RS422A Conversion Unit
Pin Signal
Pin Signal PinSignal Signal
Shield
Hood
Hood
Remote device
Signal
Remote device
(See note)
1
3
2
4
5
6
7
8
9
FG
SD
SD
RD
RD
RS
CS
+5V
DR
ER
SG
FG
RS
CS
+5V
DR
ER
SG
FG
1
2
3
4
5
6
7
8
9
Pin Signal PinSignal
SYSMAC PLC
NT-AL001 end (inside NT-AL001)
Hood Hood
Loopback
Loopback
*Arrows indicate
signal directions
Wiring with XW2Z-îî0T -1 (10 conductors)
Not used.
Shield
To Next Page
