Omron CP1E Series User Manual

2-17
2 Basic System Configuration and Devices
CP1E CPU Unit Hardware User’s Manual(W479)
2-4 Unit Current Consumption and External
Power Supply Capacity
2
2-4-2 Current Consumption
z Expansion I/O Units and Expansion Units
Unit name Model number
Current consumption
5 VDC 24 VDC
Expansion I/O Units 8 inputs CP1W-8ED 0.018A −
8 outputs CP1W-8ER 0.026A 0.044A
CP1W-8ET 0.075A −
CP1W-8ET1
16 outputs CP1W-16ER 0.042A 0.090A
CP1W-16ET
CP1W-16ET1
0.76A −
20 I/O points
12 inputs
8 outputs
CP1W-20EDR1 0.103A 0.044A
CP1W-20EDT 0.130A −
CP1W-20EDT1
32 outputs CP1W-32ER 0.44A 0.131A
CP1W-32ET
CP1W-32ET1
0.113A −
40 I/O points
24 inputs
16 outputs
CP1W-40EDR 0.080A 0.090A
CP1W-40EDT 0.160A −
CP1W-40EDT1
Expa-
nsion
Units
Analog Input
Unit
4 inputs CP1W-AD041 0.1A 0.09A
Analog Output
Unit
4 outputs CP1W-DA041 0.080A 0.124A
Analog I/O Unit Analog inputs: 2
Analog outputs: 1
CP1W-MAD11 0.083A 0.110A
Temperature
Sensor Units
K or J thermocou-
ples
CP1W-TS001 0.040A 0.059A
CP1W-TS002
Pt or JPt platinum
resistance ther-
mometers
CP1W-TS101 0.054A 0.073A
CP1W-TS102
CompoBus/S
I/O Link Unit
8 inputs
8outputs
CP1W-SRT21 0.029A −

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
