3 Part Names and Functions
3-28
CP1E CPU Unit Hardware User’s Manual(W479)
*1 If the ambient temperature is maintained below 50ºC, up to 0.9 A/common can be used.
*2 The fuse cannot be replaced by the user. Replace the Unit if the fuse breaks due to an short-circuit or overcur-
rent.
Precautions for Safe Use
Do not connect a load to an output terminal or apply a voltage in excess of the maximum switch-
ing capacity.
0.9
0.8
(A)
0
50 55 (˚C)
Total current per common
Ambient temperature
To Next Page
