Omron CP1E Series User Manual

4-1
4
CP1E CPU Unit Hardware User’s Manual(W479)
4
This section describes the features of the CX-Programmer for CP1E used for program-
ming and debugging PLCs, as well as how to connect the PLC with the Programming
Device.
4-1 CX-Programmer for CP1E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-1-1 Applicable Programming Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-1-2 CX-Programmer for CP1E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4-1-3 Operating Environment and System Configuration . . . . . . . . . . . . . . . . . . . . . 4-3
4-1-4 Features of the CX-Programmer for CP1E . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4-1-5 Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4-2 Connecting by USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4-2-1 Connecting by USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
4-2-2 Installing the USB Driver for CP1E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Programming Device

Omron CP1E Series Specifications

General

Data Memory	8K words
Pulse Output	100 kHz for 2 axes
Communication Ports	RS-232C, USB
Mounting	DIN rail mounting
Analog Inputs	Optional (via expansion units)
Analog Outputs	Optional (via expansion units)
Expansion Units	Digital I/O, Analog I/O, Temperature Sensor Units
Power Supply	100 to 240 VAC or 24 VDC
CPU Type	Various (E, N, and NA types)
