111
Pulse I/O Board Section 2-2
Pulse Output with Trapezoidal Acceleration/Deceleration and Separate
Acceleration/Deceleration Rates
The only limitation that exists is that ACC(––) (ACCELERATION CONTROL)
in Mode 0 (Acceleration + Independent) cannot be used in High-speed
Counter Mode.
The setting in DM 6611 is read only when the CQM1H is started. If this setting
is changed, the PC must be turned OFF and ON again to enable the new
value.
Operation Settings for Ports 1 and 2 (DM 6643 and DM 6644)
The diagram below shows how port 1 (DM 6643) and port 2 (DM 6644) are
set to perform fixed duty factor pulse output, which is the default pulse output
format. The settings for ports 1 and 2 can differ.
Variable duty factor pulses cannot be output from a port if it has been set to
perform standard pulse output.
Examples
The following examples show programs that controls pulse output from ports
1 and 2. Before running the programs, check that the settings in the PC Setup
are as follows:
DM 6611: 0001 (Simple Positioning Mode)
DM 6643: 0000 (Fixed duty factor pulse output from port 1)
DM 6644: 0000 (Fixed duty factor pulse output from port 2)
Instruction PULS(65) ACC(––) INI(61) PRV(62)
Function Sets number of
pulses
Acceleration/
Deceleration
rates (separate
settings)
Sets frequency
Starts pulse
output
Stops pulse
output
Reads pulse
output status
(Used in combination.)
High-speed
Counter
Mode
Enabled Mode 0 (Acc.+
Independent):
Disabled
Mode 3:
Enabled
Enabled
Simple
Positioning
Mode
Enabled
DM 6643
Bit
15 0
0
Port 1 Pulse Type
0: Fixed duty factor pulse output
Set to fixed duty factor when per-
forming standard pulse output.
1: Variable duty factor pulse output
Default: 0
(Fixed duty factor pulse output)
15 0
DM 6644
0
Bit
Port 2 Pulse Type
0: Fixed duty factor pulse output
Set to fixed duty factor when per-
forming standard pulse output.
1: Variable duty factor pulse output
Default: 0
(Fixed duty factor pulse output)
