Omron CQM1H - PROGRAM User Manual

486
Cycle Time Section 7-3
62 PRV Built-in High-speed counter 0 or pulse output from an output bit: 1.875
82.4 Designating output via word
105.7 Designating output via *DM
High-speed counters 1 to 4 on High-speed Counter Board:
115.0 Designating output via word (reading status)
132.0 Designating output via *DM (reading status)
124.0 Designating output via word (reading PV)
142.0 Designating output via *DM (reading PV)
High-speed counters 1 and 2 or pulse output from ports 1 and 2 on Pulse I/O
Board:
206.4 Designating output via word (reading status)
224.4 Designating output via *DM (reading status)
206.9 Designating output via word
(reading range comparison results)
230.7 Designating output via *DM
(reading range comparison results)
High-speed counters 1 and 2 on Absolute Encoder Interface Board:
203.7 Designating output via word (reading status)
228.0 Designating output via *DM (reading status)
205.0 Designating output via word
(reading range comparison results)
228.0 Designating output via *DM
(reading range comparison results)
63 CTBL Built-in high-speed counter 0 or pulse output from an output bit: 1.875
189.3 Target table with 1 target in words and start
210.5 Target table with 1 target in *DM and start
1.18 ms Target table with 16 targets in words and start
1.20 ms Target table with 16 targets in *DM and start
1.13 ms Range table in words and start
1.14 ms Range table in *DM and start
153.8 Target table with 1 target in words
174.9 Target table with 1 target in *DM
1.14 ms Target table with 16 targets in words
1.18 ms Target table with 16 targets in *DM
981.0 Range table in words
999.0 Range table in *DM
High-speed counters 1 to 4 on High-speed Counter Board:
152.0 Target table with 1 target in words and start
168.0 Target table with 1 target in *DM and start
1.05 ms Target table with 48 targets in words and start
1.07 ms Target table with 48 targets in *DM and start
718.0 Range table in words and start
735.0 Range table in *DM and start
152.0 Target table with 1 target in words
168.0 Target table with 1 target in *DM
1.05 ms Target table with 48 targets in words
1.07 ms Target table with 16/48 targets in *DM
718.0 Range table in words
735.0 Range table in *DM
Code Mnemonic ON execution
time (µs)
Conditions OFF execution
time (µs)

Omron CQM1H - PROGRAM Specifications

General

I/O Capacity	Up to 512 points
Power Supply	100 to 240 VAC, 50/60 Hz or 24 VDC (depending on model)
Instruction Set	Basic and advanced instructions
Operating Temperature	0 to 55°C
Program Capacity	7.2K to 15.2K steps
Communication Ports	RS-232C
Expansion Slots	Up to 3 expansion units
Type	Programmable Logic Controller (PLC)
CPU Type	RISC
Program Memory	7.2K to 15.2K steps
I/O Points	512 max
Expansion Capability	Up to 3 expansion units
Data Memory	RAM (battery backup)
