Omron CQM1H - PROGRAM User Manual

485
Cycle Time Section 7-3
61 INI Built-in High-speed counter 0 or pulse output from an output bit: 1.875
81.6 Starting comparison via word
103.0 Starting comparison via *DM
64.9 Stopping comparison via word
74.7 Stopping comparison via *DM
147.3 Changing PV via word
164.0 Changing PV via *DM
50.8 Stopping pulse output via word
72.2 Stopping pulse output via *DM
High-speed counters 1 to 4 on High-speed Counter Board:
94.0 Starting comparison via word
112.0 Starting comparison via *DM
94.0 Stopping comparison via word
112.0 Stopping comparison via *DM
136.0 Changing PV via word
154.0 Changing PV via *DM
High-speed counters 1 and 2 or pulse output from ports 1 and 2 on Pulse I/O
Board:
267.2 Starting comparison via word
291.9 Starting comparison via *DM
186.6 Stopping comparison via word
209.6 Stopping comparison via *DM
421.5 Changing PV via word
439.1 Changing PV via *DM
223.9 Stopping pulse output via word
242.9 Stopping pulse output via *DM
High-speed counters 1 and 2 on Absolute Encoder Interface Board:
266.7 Starting comparison via word
285.1 Starting comparison via *DM
182.1 Stopping comparison via word
203.7 Stopping comparison via *DM
Code Mnemonic ON execution
time (µs)
Conditions OFF execution
time (µs)
