Auto Focus Multi Code Reader V430-series User’s Manual (Z392) A-5
Appendices
Read Ranges
V430-F000W50C
QSXGA Standard Density, Wide View
V430-F000M50C
QSXGA High Density, Middle View
V430-F000W12M
SXGA Standard Density, Wide View
V430-F000M12M
SXGA High Density, Middle View
V430-F000N12M
SXGA Ultra High Density, Narrow View
Focal Distance
(mm)
Field of View (mm) Read Ranges (mm)
Typical 2D Ele-
ment Size (mm)
Horizontal Vertical Inside Outside
50 51 37 43 59 0.13
102 96 75 80 124 0.19
300 265 210 203 397 0.38
Focal Distance
(mm)
Field of View (mm) Read Ranges (mm)
Typical 2D Ele-
ment Size (mm)
Horizontal Vertical Inside Outside
50 35.5 25 46.5 54.5 0.13
102 66 49 94 110 0.13
300 184 143 227 373 0.38
Focal Distance
(mm)
Field of View (mm) Read Ranges (mm)
Typical 2D Ele-
ment Size (mm)
Horizontal Vertical Inside Outside
50 57.2 42.9 37 64 0.19
102 109.5 82.2 74 131 0.26
300 314.3 235.7 224 427 0.77
Focal Distance
(mm)
Field of View (mm) Read Ranges (mm)
Typical 2D Ele-
ment Size (mm)
Horizontal Vertical Inside Outside
50 36.5 27.4 47.5 55 0.13
102 71.4 53.6 88 116 0.19
300 198.4 148.8 185 400 0.51
Focal Distance
(mm)
Field of View (mm) Read Ranges (mm)
Typical 2D Ele-
ment Size (mm)
Horizontal Vertical Inside Outside
40 10.0 7.5 38.5 41.5 0.09
81 20.5 15.5 78.5 83.5 0.09
150 39.0 29.5 132 153 0.13
