ORKEL MP2000-X - Page 113

Loc. Terminal block function Comment
X12.3 GND - I/O
X12.4 GND - I/O
X12.5 GND - I/O
X12.6 GND
X12.7 GND
X12.8 GND
X13.1 Supply - CU1 870-831
X13.2 Supply - CU2 870-831
X13.3 E-stop relay 870-831
X13.4 E-Stop circuit 870-826
X13.5 E-Stop circuit 870-826
X13.6 Various 870-826
X13.7 Various 870-826
X13.8 LED lamps 870-831
X13.9 Lights, alternator, auxiliary 870-831
X13.10 Lights, alternator, auxiliary 870-831
X13.11 Film storage 870-831
X13.12 CANbus, high 870-831
X13.13 CANbus, high 870-831
X13.14 CANbus, low 870-831
X13.15 CANbus, low 870-831
10.6.2 Supply block 2
Left Middle-left Middle
Middle-
right
Right Left
- W. guard valve
- Display unit [Br]
- To X13.9
- To X13.5
- Cooler fan [R]
- E-stop relay, 1
- E-stop relay, 3
- - Battery, positive
- - Battery, negative
Sensor S14 [Wh] Chamber CU 4.1 Chamber CU 4.3
Cooler fan [Bk] Wrapper CU 4.1 Wrapper CU 4.3
LED lamp [y] To X1.11 To X5.11
LED lamp [y] To X2.11 To X6.11
LED lamp [y] To X3.11 To X7.11
Check valve [2] F.storage valve [2] Display unit [Bl]
E-stop relay, A2 To X3.17 (Ca.de.)
E-stop relay, 2 Cooler fan relays p85 Chamber CU 4.4 Chamber CU 4.5
E-stop relay, 4 To X7.17 (Ca.de.) Wrapper CU 4.4 Wrapper CU 4.5
10 ELECTRICS 113
