Valves, HIC1, HIC2 and HIC3
ID Description Loc. Type Hi Mid Low
V33 Cooler fan run (suck) X2.18 DO Bk
V34 Cooler fan reverse (blow) X2.21 DO Bk
V35 Air cleaning, door (OPT) X1.18 DO ·1 ·2
V36 Elevator and ch. door speed X1.7 PWM ·1
V36 Elevator and ch. door speed FB X1.6 FB ·2
V37 S.conveyor & F.hopper speed X2.2 PWM ·1
V37 S.conveyor & F.hopper speed FB X2.3 FB ·2
V39 Elevator bypass X2.7 DO ·1 ·2
V40 Net brake release X1.8 DO ·1 ·2
10.7.3 IO list 3
Valves, HIC4 (F25)
ID Description Loc. Type Hi Mid Low
V51 Run feed hopper X2.9 DO ·1 ·2
V52 Run flip X2.10 DO ·1 ·2
V53 Flip change direction X6.5 DO ·1 ·2
V54 Flip check right X6.6 DO ·1 ·2
V55 Flip check left X6.7 DO ·1 ·2
V56 Auger bypass X5.16 DO ·1 ·2
10.8 INPUTS AND OUTPUTS SORTED BY TYPE
10.8.1 Inductive sensors
Inductive sensors
ID Description Loc. Hi Mid Low
S03 Table middle position X5.20 Bk Bl Br
S05 Wrapping arm home position X6.19 A.Bk A.Y A.R
S08 Wrapping arm stop X6.20 A.Br
S09 Table lower position X6.22 Bk Bl Br
S10 Table upper position X6.23 Bk Bl Br
S11 Film sensor 1 X7.19 A.Bl
S12 Film sensor 2 X7.20 A.Gn
S16 Chamber dampening X3.13 Bk Bl Br
S17 Chamber opened X1.19 Bk Bl Br
S18 Chamber closed X1.20 Bk Bl Br
S19 Feed rollers opened X2.19 Bk Bl Br
S20 Feed rollers closed X2.20 Bk Bl Br
S22 Net knife closed X3.14 Bk Bl Br
S31 Chamber speed X3.20 Bk Bl Br
S32 Net control X3.21 Bk Bl Br
S35 Elevator speed X3.22 Bk Bl Br
10 ELECTRICS 116
