l Feed hopper lifting cylinders, jack stands, film roller storage, and drawbar.
All functions are operated through manual levers on the machine. See section 4.2.3 "Lever/Controls over-
view"
IMPORTANT: Check that all the valves between the oil tank and hydraulic pumps are opened before the PTO is
started.
NOTE: For energy preservation flow rate from tractor should be set no higher than 30 l/min. Oil port should be
turned off when not in use.
4.2.11 Oil temperature
The oil temperature is shown in the top left corner on the display unit main page. If the oil is too cold, run
the PTO at maximum 300 rpm until the minimum start temperature is reached. See temperature values
below.
IMPORTANT: Starting the PTO drive shaft with full speed at a too low temperature may harm the hydraulic sys-
tem.
Heating the oil may take up to 25 minutes. A sticker on the oil tank indicates the applied oil type.
IMPORTANT: Run the PTO at 300 rpm until the minimum start temperature is reached.
Titan Transway WB: Minimum start temperature: 5°C / 50°F When the minimum start temperature is
reached, increase the PTO speed to 850 rpm.
4.2.12 Stairs
Unfold: The compactor is equipped with foldable stairs. The stair may be unfolded to working position as fol-
lows:
1. Pull the lever towards you and pull the stairs out from the machine until the support is fully exten-
ded.
2. Push the lever away from yourself and carefully fold the lower part of the stairs outwards and down.
Fold: The stair may be folded back into transport position as follows:
1. Carefully fold the lower part of the stairs upwards and in. Ensure that the lock engages.
2. Hold the upper stair segment and fold the middle of the support upwards and in. Ensure that the
lock engages.
Ensure that the stairs are properly locked before transporting the machine.
4.3 DAILY CHECKLIST
4.3.1 Daily checklist prior to startup
No Checkpoint prior to startup
1 Ensure that the drawbar is set in operational position.
2 Check that all main valves are open.
3 Check chain oil and grease level.
4 Check if grease comes out from the pressure relief valve on the grease pump unit (indicates blocking of
pipe).
4 OPERATION 38
