6 Control system
6.1 User interface 50
6.1.1 Main page 50
6.1.2 Icons for starting program sequences 51
6.1.3 Menu 51
6.1.4 User settings [Language and screen] 52
6.1.5 System information 53
6.1.6 Manual controls 53
6.1.7 Machine settings 55
6.1.8 Quick settings 56
6.1.9 Presets 57
6.1.10 Sensors 57
6.1.11 Messages 58
6.1.12 Time and date 59
6.1.13 User data 59
6.1.14 Weighing system 61
6.1.15 Reset 61
6.1.16 Software 61
6.1.17 Settings and explanations 63
6.1 USER INTERFACE
This section provides a brief introduction to the user interface, so that you quickly can get started using
the machine.
NOTE: Software reviewed by this chapter is 0.17.03. Variations from the illustrations may occur.
The display unit is connected to the machine through its own cable from the machine’s electro cabinet. The
display unit is normally mounted on a ball joint. The mount may be opened so that the display unit can be
brought around the machine. The display unit should be stored indoors when not in use. Keep the con-
nectors dry and clean at all time.
6.1.1 Main page
When the main power switch is turned on, the display will boot. After a few seconds, the main page will
appear.
6 CONTROL SYSTEM 50
