Valves, HIC4 (F25)
ID Description Loc. Hi Mid Low
V52 Run flip X2.10 ·1 ·2
V53 Flip change direction X6.5 ·1 ·2
V54 Flip check right X6.6 ·1 ·2
V55 Flip check left X6.7 ·1 ·2
V56 Auger bypass X5.16 ·1 ·2
10.8.9 Cable detection
Cable detection (Automatic controller identification)
ID Description Loc. Hi Mid Low
Cable detection X3.17 X12.8
Cable detection X7.17 X13.2
10 ELECTRICS 119
