Loc. ID Description Type Hi Mid Low
X6.23 S10 Table upper position DI Bk Bl Br
10.5.6 IO block 7
Loc. ID Description Type Hi Mid Low
X7.1 ---------- NOT IN USE ----------
X7.2 - V5 reference voltage
X7.3 ---------- NOT IN USE ----------
X7.4 ---------- NOT IN USE ----------
X7.5 S42 Flip up DI C.Wh
X7.6 S43 Flip down DI C.Bk
X7.7 ---------- NOT IN USE ----------
X7.8 ---------- NOT IN USE ----------
X7.9 ---------- NOT IN USE ----------
X7.10 ---------- NOT IN USE ----------
X7.11 ---------- NOT IN USE ----------
X7.12 ---------- NOT IN USE ----------
X7.13 ---------- NOT IN USE ----------
X7.14 ---------- NOT IN USE ----------
X7.15 ---------- NOT IN USE ----------
X7.16 S33 RF remote ctrl. Stop (OPT) DI Wh
X7.17 Cable detection DI X13.2
X7.18 ---------- NOT IN USE ----------
X7.19 S11 Film sensor 1 PI A.Bl
X7.20 S12 Film sensor 2 PI A.Gn
X7.21 S34 RF remote ctrl. Drop (OPT) DI Bk
X7.22 S46 RF remote ctrl. Aux (OPT) DI Gy
X7.23 ---------- NOT IN USE ----------
10.6 POWER SUPPLY
10.6.1 Supply block 1
Loc. Terminal block function Comment
X10.0 Fuse - wrapper guard valve 3 A
X10.1 Fuse - display unit 3 A
X10.2 Fuse - lights, alternator 10 A
X10.3 Fuse - Emergency stop circuit 5 A
X10.4 Fuse - cooler fan 15 A
X10.5 Fuse - CU1 (chamber) 15 A
X10.6 Fuse - CU2 (wrapper) 15 A
X11.1 Main power, positive, 24 Vdc
X11.2 Main power, negative, GND
X12.1 GND - Chamber
X12.2 GND - Wrapper
10 ELECTRICS 112
