8 Lubrication
8.1 Lubrication system, beka max EP 1 92
8.1.1 Oil lubrication, mode of operation 92
8.1.2 Grease lubrication, mode of operation 92
8.1.3 Beka max grease lubrication system 94
8.2 Refilling lubricants 94
8.2.1 Refilling the oil reservoir 95
8.2.2 Adjusting the amount of grease 95
8.2.3 Bleeding the grease system 95
8.3 Electric pump and main distributor 96
8.4 Troubleshooting for Beka max 96
8.5 Oil temperature 97
8.6 Approved lubricants 97
8.6.1 Hydraulics 97
8.6.2 Chain lubrication 97
8.6.3 Greasing 97
8.6.4 Gearbox and gears for hydraulic motors 98
8.7 Manual lubrication charts 99
8.7.1 The compactor 99
8.7.2 Feed hopper F10 100
8.7.3 Telescopic drawbar 101
8.8 Lubrication list - Manual greasing points 102
8.1 LUBRICATION SYSTEM, BEKA MAX EP 1
The compactor is equipped with a fully automatic lubrication system. It lubricates the chamber roller bush-
ings (grease) and the chains (oil).
8.1.1 Oil lubrication, mode of operation
A single piston pump driven by the hydraulic pressure, supplies oil to the chains through brushes which are
mounted on strategic locations. Each time the chamber door opens, the piston is activated and supplies a
fixed amount of oil to the chains.
8.1.2 Grease lubrication, mode of operation
An electrical motor runs an eccentric disc. The eccentric disc drives two single working pistons which push
a fixed amount of grease through a pressure relief valve, and further on to a main distributor. The main dis-
tributor supplies grease to sub-distributors, which deliver the correct amount of grease to each bearing.
8 LUBRICATION 92
