10.8.4 Sensors, 7-lead cable
Sensors, 7-lead cable from wrapper
ID Description Loc. Hi Mid Low
S01 Bale on wrapping table X5.19 A.Wh
S05 Wrapping arm home position X6.19 A.Bk A.Y A.R
S08 Wrapping arm stop X6.20 A.Br
S11 Film sensor 1 X7.19 A.Bl
S12 Film sensor 2 X7.20 A.Gn
10.8.5 Film system remote control
Film system remote control
ID Description Loc. Hi Mid Low
S37 Remote open feed rollers X2.17 B.Bl B.Br
S38 Remote close feed rollers X2.22 B.Y
S39 Remote start film system X2.23 B.Gn
10.8.6 Radio remote control
Radio remote control
ID Description Loc. Hi Mid Low
S33 RF remote ctrl. Stop (OPT) X7.16 Wh
S34 RF remote ctrl. Drop (OPT) X7.21 Bk
S46 RF remote ctrl. Aux (OPT) X7.22 Gy
10.8.7 Proportional valves
Proportional valves, pump servo and grease pump (PWM)
ID Description Loc. Hi Mid Low
V13 Grease pump X5.4 Bl
V13 Grease pump FB X5.5 Br
V30 Wrapper speed X6.1 ·1
V30 Wrapper speed FB X6.3 ·2
V32 Chamber speed pump X2.5 ·1
V32 Chamber speed pump FB X2.4 ·2
V36 Elevator and ch. door speed X1.7 ·1
V36 Elevator and ch. door speed FB X1.6 ·2
V37 S.conveyor & F.hopper speed X2.2 ·1
V37 S.conveyor & F.hopper speed FB X2.3 ·2
10.8.8 Valves
Valves, HIC4 (F25)
ID Description Loc. Hi Mid Low
V51 Run feed hopper X2.9 ·1 ·2
