6.1.17 Settings and explanations
Settings Explanation
Chamber speed, baling Chamber speed during baling
Chamber speed, net feed Chamber speed during net/film feed
Chamber speed, net pull Chamber speed when net/film is put on the bale
Chamber speed, drop Chamber speed when bale is ejected from the chamber. Import-
ant in context of both stiction and loss
Chamber max pressure Pressure limit at which the net/film sequence starts (maximum
chamber pressure)
Elevator show threshold Pressure limit at which the elevator slows down
Elevator speed, fast Elevator speed when material is fed into the chamber, high level
(before Elevator slow threshold is reached)
Elevator speed, slow Elevator speed when Elevator slow threshold is reached
B-belt speed, recycling Sub conveyor speed when recycling (baling)
B-belt speed, transport Sub conveyor speed when transporting the bale from chamber to
wrapping table. Low speed normally reduces material loss
Net/film failure monitoring Defines whether the system stops upon failure of net/film system
sequence (known as Net control)
Laps of net/film Defines the number of rounds of net/film in the net/film sequence.
Counted from completed feeding
Laps of wrapping film Defines whether the system stops upon failure of wrapping
sequence (known as Film control)
US trigger distance Defines the number of rounds of film in the wrapping sequence.
Note: not number of layers
Bale-on-table-delay Delay before the table moves to its middle position after detect-
ing bale. Should be set shorter at higher transport speed on sub
conveyor
Net/film tying start delay Delay before the net/film system starts when the maximum cham-
ber pressure is reached
Elevator stop delay Delay before the elevator stops when the maximum chamber pres-
sure is reached
Net/film feed duration Defines the duration of net/film feed when the net/film sequence
starts
Wrapping table speed, two rollers Defines the wrapping table belt speed when wrapping with two
rollers. Determines the net/film overlap
Wrapping table speed, one roller Defines the wrapping table belt speed when wrapping with one
roller. Determines the net/film overlap
Elevator overfeed protection Activates automatic stop of the hopper if the pressure exceeds
the set maximum pressure.
Elevator overfeed limit Defines the maximum pressure in the elevator, that is, the
threshold at which the hopper stops
Film release, 1st Defines at which of the wrapper rounds the cutters releases the
film, first time
6 CONTROL SYSTEM 63
