Settings Explanation
Film release, 2nd Defines at which of the wrapper rounds the cutters releases the
film, second time
Film release, 3rd Defines at which of the wrapper rounds the cutters releases the
film, third time
Film release duration Defines the duration of the cutter film release. Should be adjusted
in context of the cutters speed (manual valve)
Bale drop dwell time Defines the wrapping tables dwell in lower position during bale
drop. Chosen based on material weight and firmness, as well as
whether the belt rotates
Auto continuation, one roller Activates automatic reset of the wrapping table belt speed when
wrapping with one roller. Used to maintain the correct overlap
when one roller empties
Feed rollers rotate @ closing Defines whether the feed rollers rotate during closing. Used to pro-
tect the net/film
wrapping table run during drop Defines whether the wrapping table belts rotates during the bale
drop. If activated, the bale may roll further away from the
machine
Bale eject additional rotation Defines an additional rotation of the bale when ejected from the
chamber. Used to place the net/film "tale" on top of the bale
Hopper run during transport Defines whether the feed hopper runs when the bale is being
transported to the wrapper. May be used to prefill the elevator
before the next bale
Grease amount Defines the amount of grease pumped to the lubrication points
Delayed hopper start Defines a delayed start of the hopper after the elevator has star-
ted
Wrapping table run before drop Defines whether the wrapping table rotates in order to squeeze
the film before bale drop
F25: Augers low speed run For F25 only: Defines whether the augers rotates then the elev-
ator runs at low speed
F25: Hopper full flow For F25 only: Defines whether the hopper runs at full speed at all
(both pumps connected)
F25: Hopper full flow delay For F25 only: Defines a delay before the hopper runs at full speed
6 CONTROL SYSTEM 64
