ORKEL MP2000-X - Valve List for MP2000-X

11.2.2 Valve list for MP2000-X
Valve number Description Location
K1 Chamber, closing speed In cabinet, on valve block
K2 Safety valve, chamber door cylinder Chamber, cylinder, right hand side
K3 Safety valve, chamber door cylinder Chamber, cylinder, left hand side
B1 Plastic tying unit, feed speed Plastic tying unit
B2 Plastic tying unit, brake force Plastic tying unit
M1 Feed hopper, speed In cabinet, on valve block
M2 Feed hopper, transport safety valve Feed hopper, cylinder, right hand side
M3 Feed hopper, transport safety valve Feed hopper, cylinder, left hand side
P1 Wrapper, speed, high In cabinet, on valve block
P2 Wrapper, speed, low In cabinet, on valve block
P3 Wrapping table, tilt speed In cabinet, on valve block
P4 Film cutter, left, speed In cabinet, on valve block
P5 Film cutter, right, speed In cabinet, on valve block
T1 Tank valve Under, on tank
T2 Tank valve Under, on tank
T3 Tank valve Under, on tank
T4 Tank valve Under, on tank
