12 Specifications
12.1 Electrical system 130
12.2 Power take off 130
12.3 Lubrication system beka-max 130
12.4 Hydraulic system 131
12.5 Wheels and tyres 131
12.6 Dimensions and weight 131
12.6.1 Measurements 131
12.6.2 Power requirements 131
12.6.3 Dimensional sketch F10, operating mode 132
12.6.4 Dimensional sketch F10, transport mode 133
12.1 ELECTRICAL SYSTEM
Power supply:
24 Vdc with alternator located by the pump unit and dual 12 V 55 Ah
lead acid batteries in series.
Sensors:
Position detected Inductive Pepperl+Fuchs NBB8-18GM50-E2-V1
Feed hopper: Ultrasonic, analogue Pepperl+Fuchs UC2000-30GM70-IE2R2-V15
Wrapping table: Ultrasonic, digital (70 cm def.) Microsonic mic+130/D/TC
Oil temperature: PT1000 FuehlerSysteme EF5/E-20/5
Oil level: Photoelectric lever Carlo Gavazzi VP04EP
Chamber pressure: Pressure, 0-600 bar IFM PT5460
Elevator pressure: Pressure 0-250 bar IFM PT5401
12.2 POWER TAKE OFF
Maximum torque: 2900 Nm
Speed: 850 RPM
12.3 LUBRICATION SYSTEM BEKA-MAX
Grease system:
Voltage 24 Vdc
Maximum current 1,1 A
Pump capacity each revolution
Pump 1 (fixed amount) 0,17 cm³
Pump 2 (adjustable) 0,04 - 0,12 cm³
Pump capacity each minute 4,3 cm³/minute
Maximum pressure 280 bar
Grease type EP 2 NLGI-2
Volume reservoir 4,0 l
Chain lubrication:
