Take care when assembling/mounting the compactor. Squeezing of body parts and injuries from falling can
occur when maneuvering the wrapping table.
Max. height in operation position: 3900 mm
4.1.5 Elements of hazard during operation
If you fail to comply with instructions given it could result in personal injury or loss of life.
Pay attention to the risk of:
l squeezing/crushing/cutting of fingers or hands near the knife for plastic tying unit.
l squeezing/crushing of fingers or hands between conveyor belts and sprockets.
l squeezing/crushing of fingers or hands between belt and roller, and under the wrapping table.
l squeezing/crushing of body and feet when bale is dropped from the wrapping table.
l squeezing/crushing of fingers or hands between wrapping arms and frame.
l impact from rotating wrapping arms.
l sensor on wrapping table might fail, causing a too early bale drop.
l a burst in a hydraulic line/hose with high pressure- and heated oil can cause severe injury to eyes
and skin.
4.1.6 Danger zones during operation
The left side of the compactor is a blind spot. The operator must always be sure there’s no one present in
this area, before start up and during operation.
Maintain the boundaries of the danger zone as described in section 2.4.6 "Danger zones".
4.1.7 Risk of overturning
The operator must take precautions to avoid risk of overturning. Both during rigging, set-up
and when operating the machine.
4.1.8 Leaving the machine
Before leaving the machine, the operator must turn off the engine (tractor) or any other
power source. Remove key or secure the power source to avoid unattended start.
4.2 CONNECTION AND SETTING UP THE MACHINE
4.2.1 Rig up
IMPORTANT: Be aware of the danger of tipping when rigging up.
