Raise wrapping table Lower wrapping table
Open film cutters Close film cutters
Run wrapper, low speed Run wrapper, high speed
Run wrapper to home position Run wrapper, complete sequence
Open chamber door Close chamber door
Run chamber
Shortcut to machine settings
(applies to both page 1 and page 2)
Open net/film knife Close net/film knife
Open feed rollers Close feed rollers
Start net/film sequence Net/film brake off/on
Run wrapping table belt Start bale drod
Reverse cooler fan (self cleaning) Sound warning siren
Flash signal tower Run grease pump
6.1.7 Machine settings
From main page; press Menu and then the icon for Machine settings. This page allows you to
change settings that determines the machine behaviour during operation.
For more information of each setting and what it is used for, see section 6.1.17 "Settings and explan-
ations"
NOTE: The machine settings cannot be viewed or changed if one or more of the emergency stop switches are
triggered, or if the machine is running in auto mode.
6 CONTROL SYSTEM 55
