10.8.2 Other sensors and switches
Other sensors and switches
ID Description Loc. Hi Mid Low
S01 Bale on wrapping table X5.19 A.Wh
S29 Feed hopper US-sensor X3.6 Gy Bl Br
S14 Oil temperature X5.12 Bk
S27 Oil level X6.16 Bk Bl Br
S28 Grease level X6.17 Bk Bl Br
S30 Chamber pressure X3.5 Wh Br
S41 Elevator load (pressure) X2.12 Wh Br
S07 E-Stop redundancy input X2.16 X13.3
S47 Thermo switch X3.16 R Y
10.8.3 Directional valves
Directional valves and check valves, HIC1, HIC2 and HIC3
ID Description Loc. Hi Mid Low
V01 Sub conveyor bypass X2.1 ·1 ·2
V02 Chamber open X1.1 ·1 ·2
V03 Chamber close X1.2 ·1 ·2
V04 Wrapper bypass off X1.3 ·1 ·2
V05 Table up X5.1 ·1 ·2
V06 Table down X5.2 ·1 ·2
V07 Run wrapping table X5.3 ·1 ·2
V08 Net knife cut X1.14 ·1 ·2
V09 Wrapping arm slow X5.7 ·1 ·2
V10 Wrapping arm fast X5.8 ·1 ·2
V11 Film knife open X5.14 ·1 ·2
V12 Film knife close X5.15 ·1 ·2
V17 Net feed rollers open X1.15 ·1 ·2
V18 Net feed rollers close X1.16 ·1 ·2
V19 Net feed motor X1.17 ·1 ·2
V24 Sub conveyor on X2.8 ·1 ·2
V25 Feed hopper on X2.6 ·1 ·2
V31 Bale drop warning buzzer X5.17 R Y
V33 Cooler fan run (suck) X2.18 Bk
V34 Cooler fan reverse (blow) X2.21 Bk
V35 Air cleaning, door (OPT) X1.18 ·1 ·2
V39 Elevator bypass X2.7 ·1 ·2
V40 Net brake release X1.8 ·1 ·2
10 ELECTRICS 117
