All sensors
ID Description Loc. Type Hi Mid Low
S31 Chamber speed X3.20 PI Bk Bl Br
S32 Net control X3.21 PI Bk Bl Br
S33 RF remote ctrl. Stop (OPT) X7.16 DI Wh
S34 RF remote ctrl. Drop (OPT) X7.21 DI Bk
S35 Elevator speed X3.22 PI Bk Bl Br
S37 Remote open feed rollers X2.17 DI B.Bl B.Br
S38 Remote close feed rollers X2.22 DI B.Y
S39 Remote start net X2.23 DI B.Gn
S41 Elevator load (pressure) X2.12 AI Wh Br
S42 Flip up X7.5 DI C.Wh
S43 Flip down X7.6 DI C.Bk
S44 Feed hopper start X3.7 DI C.Gn
S45 Feed hopper stop X3.8 DI C.R
S46 RF remote ctrl. Aux (OPT) X7.22 DI Gy
S47 Thermo switch X3.16 DI R Y
10.7.2 IO list 2
Valves, HIC1, HIC2 and HIC3
ID Description Loc. Type Hi Mid Low
V01 Sub conveyor bypass X2.1 DO ·1 ·2
V02 Chamber open X1.1 DO ·1 ·2
V03 Chamber close X1.2 DO ·1 ·2
V04 Wrapper bypass off X1.3 DO ·1 ·2
V05 Table up X5.1 DO ·1 ·2
V06 Table down X5.2 DO ·1 ·2
V07 Run wrapping table X5.3 DO ·1 ·2
V08 Net knife cut X1.14 DO ·1 ·2
V09 Wrapping arm slow X5.7 DO ·1 ·2
V10 Wrapping arm fast X5.8 DO ·1 ·2
V11 Film knife open X5.14 DO ·1 ·2
V12 Film knife close X5.15 DO ·1 ·2
V13 Grease pump X5.4 DO Bl
V13 Grease pump FB X5.5 DO Br
V17 Net feed rollers open X1.15 DO ·1 ·2
V18 Net feed rollers close X1.16 DO ·1 ·2
V19 Net feed motor X1.17 DO ·1 ·2
V24 Sub conveyor on X2.8 DO ·1 ·2
V25 Feed hopper on X2.6 DO ·1 ·2
V30 Wrapper speed X6.1 PWM ·1
V30 Wrapper speed FB X6.3 FB ·2
V31 Bale drop warning buzzer X5.17 DO R Y
V32 Chamber speed X2.5 PWM ·1
V32 Chamber speed FB X2.4 FB ·2
10 ELECTRICS 115
