Outputs on controllers for standard system
No. Description Type Brand & type Current drawn @ 24Vdc Resistance in Ohms Comment
V8 Digital valve Comatrol SV-15-34-02 1,38 A 17
V9 Digital valve Comatrol SV-15-34-04 1,38 A 17
V10 Digital valve Comatrol EVK 06/C5 1,1 A 22
V11 Digital valve Comatrol SV-15-34-05 1,1 A 22
V12 Digital valve Comatrol SV-15-34-05 1,1 A 22
V13 Electric motor Bekamax EP-1 1,1 A at full load, 3A fuse
V17 Digital valve Comatrol SV-15-34-05 1,38 A 17
V18 Digital valve Comatrol SV-15-34-05 1,38 A 17
V19 Digital valve Comatrol SV-15-34-02 1,38 A 17
V24 Digital valve Comatrol SV-15-34-04 1,38 A 17
V25 Digital valve Comatrol SV-15-34-04 1,38 A 17
V30 Proportional valve Comatrol PSV10-NC 0,9 A (200 mA min) 16
V31 Buzzer Fulleon ROLP/SV/W/S 32 mA
V32 Servo solenoid Samhydraulik SH6V 0,68 A (230 mA min) 24,6
V33 Relay Bosch 0 332 209 206 896 0,1 A 215 Sinking output
V34 Relay Bosch 0 332 209 206 896 0,1 A 215 Sinking output
V35 Digital valvevalve Camozzi U77 0,15 A 160 Sinking output
V36 Proportional valve Comatrol PSV1-NC 0,9 A (250 mA min) 17
V37 Proportional valve Comatrol PSV1-NC 0,9 A (250 mA min) 17
V39 Digital valve Comatrol SVP10-NOR 1,1 A 22
V40 Digital valve Comatrol SVP10-NOR 1,1 A 22
V51 Digital valve Comatrol SV-15-34-03 1,38 A 17 F25 only
V52 Digital valve Comatrol SV-15-34-03 1,38 A 17 F25 only
V53 Digital valve Comatrol SV-15-34-01 1,1 A 22 F25 only
V54 Digital valve Comatrol SVP08-NCR 1,38 A 17 F25 only
V55 Digital valve Comatrol SVP08-NCR 1,38 A 17 F25 only
V56 Digital valve Comatrol EVK 06/C5 1,1 A 22 F25 only
11 HYDRAULICS 127
