Panasonic EBL512 - Event log (H4;U7)

Panasonic Eco Solutions Nordic AB
MEW01457 Rev: - Operating Instructions Fire alarm system EBL512, V2.7.x
121
"Return"
Enter technical number: 000000
Write the sensor's techn.
number and/or press "A"
to accept or press
"Return" to carry out the
change of algorithm(s).
"Return"
Alarm algorithms have been changed. The
affected CU:s will now restart. ACCEPT?
"A"
Sensor values
Printout: (1=yes) U5
Menu U5 will be shown
for a few seconds and
then the affected control
unit(s) will restart.
See chapter "Restart", page 88.
NOTE!
The new algorithm will not be in use until after the restart.
In case of an automatic log off (and one or more algorithms are
changed), the affected control unit(s) will restart.
Sensor values and setting alarm algorithm for the Analog multi
detector 3316:
The procedure is similar to the procedure for 3304 and 3308
respectively. When using "", the smoke detector information will
be shown before the heat detector information.
The algorithms can only be changed one at a time, i.e. if both
algorithms are to be changed, start with the smoke detector algorithm
and continue with the heat detector algorithm as follows:
If a smoke detector algorithm shall be changed, do as for 3304.
If a heat detector algorithm shall be changed, use "" to pass the
smoke detector windows. Then do as for 3308.
