LED indicators on the Control Panel (CP)
LED indicator
Indicating
L7
General fault (yellow)
Fault(s) (i.e. not acknowledged fault(s)) and/or
acknowledged but not corrected fault(s).
L8
Disablements (yellow)
Something in the system is disabled / disconnected.
NOTE! Also valid for "Single encapsulated reset"
12
.
L9
Test mode (yellow)
One or more zones are in "test mode".
L10
Door open (yellow)
A door is open.
15
L11
Fault tx activated (yellow)
One or more not acknowledged faults in the system
and the output Fault tx (routing equipment) is activated
(i.e. this output must not be disabled).
Test of routing equipment in progress (see menu H1).
L12
Service (yellow)
One or more sensors have reached the service level.
See menu H4/U6.
L13
Fault / Disablements
Alarm devices (yellow)
One or more outputs (type 3 = alarm device) in the
system are disabled.
Blinking: One or more supervised outputs (type 3 =
alarm device) have generated fault(s).
16
L14
System fault (yellow)
EBL512 is not running (because of S/W / CPU /
memory fault).
L15
Fault / Disablements
Fire brigade tx (yellow)
Output(s) for fire brigade tx (routing equipment)
is(are) disabled via menu (H8/S1 or H2/B3) or via an
open door.
15
Blinking: Routing equipment power supply output
17
or one or more supervised outputs (type 4 = routing
equipment) have generated fault(s).
18
L16
Fire brigade tx delay
(yellow)
The alert annunciation function is enabled, i.e. time
channel controlling this function is "on".
19
15
See also chapter "Door open", page 35.
16
This is also valid when the c.i.e. has no "contact" with a unit with such an
output, e.g. 3377, 3379, 3361, etc.
17
Connection board 1555 terminal block "P1:37-38", fuses F1 and F3.
18
This is also valid when the c.i.e. has no "contact" with a unit with such an
output, e.g. 3361, etc.
19
The Alert Annunciation function is described in the EBL512 Planning
Instructions, chapter "Alert annunciation". The LED "L16" will be "on" if
the AA function is enabled for at least one alarm point / zone. Normally is
only one time channel used for this function but two or more channels can be
used. The AA function can, as an alternative, be continuously "on".
