Push buttons / Keypad on the Control Panel (CP)
Key/push button
Operation/function
P6
Fault acknowledge
(yellow)
Used to acknowledge the faults shown in menu H6. Also used
to acknowledge SERVICE signal, see menu H8/S4.
20
P7
Paper feed (white)
Used for paper feed (when a built-in printer is available in the
c.i.e.).
P8
Access (white)
Used to log on, i.e. to get access to the menu tree (via an access
code) to carry out disablements, etc. In conjunction with fire
alarm, some information is available and some actions are
possible to perform via the "Fire alarm menu" (X1-X9) without
log on, see chapter "Fire alarm", page 41.
P9
Return (white)
Used to stop input of data, leave a menu ("one step up") and to
log off.
1 – 9 and 0
Numeric keys for the figures 0-9.
C
Used to clear /delete just written data.
A
Used to accept a menu and accept input of data.
 
 
Left / right keys are used to move the cursor in a menu.
Up / down keys are used to scroll between the menus.
20
In the New Zealand convention only, used to acknowledge a Fire alarm,
i.e. the alarm information "ALM" in the LCD is changed to "ACK".
